History

During World War II, German ally Italy received a local license for the local production of the Diamler-Benz DB 605 inline-piston engine that powered several Italian conflict front-line combatants - including the Fiat G. 55 "Centauro".', of which 274 were produced during this period. The G.55 proved to be a formidable adversary to classic Allied aircraft of the war, including the Spitfire, Mustang and Thunderbolt, and certainly earned their respect.

Italy surrendered to the Allies in September 1943, and G.55 production finally ceased.

After the war in 1946, Fiat's attempt to push the manufacture of its useful monoplane fighters eventually gave rise to the G.55A and G.55B brands - the former eventually taking shape as a single-seat fighter/advanced trainer, and the latter Become a trainer that completes use as two seats. Both Italy and Argentina put newer fighter jets into service, and this demand eventually led to a shortage of available DB 605A inline engines.

As the order for the G.55 was still pending, it was decided to convert the fighter into a British Rolls-Royce "Merlin" - the famous engine that powered the victorious Allied Spitfire and Mustang.

The first flight of the G. 55 (G. 55BM) with a Merlin engine (Merlin T. 24-2, 1,610 hp) took place in early 1948 and proved to be a healthy pairing. The Italian Air Force liked what they saw and ordered their existing G. 55 fleet to be retrofitted in the same way. Twelve G. 55AM fighters in the new "G. 59" standard, followed by 16 single-seat "G.

59-1A" and two-seat "G. 59-1B" variants for the Italians in 1950 In use, the Syrian Air Force noted and ordered 30 fighters, in the form of 26 x single-seat G. 59-2A variant (4 x 20mm gun armament) and 4 x two-seat G. 59ended-2B (2 x 12.7 mm machine gun armament) .

The G. 59 series was completed with the introduction of the single-seat G. 59-4A and two-seat G. 59-4B variants, which were fitted with a bubble canopy to improve pilot visibility. The A model also features a reduced rear body design.

The Italian Air Force took over 20 of the former and 10 of the latter. As a navigation trainer, the G. 59-3A did not surpass the prototype.

The Argentine Air Force evaluated a G.59-2A, but this did not result in a concrete production order.

When done, the G. 59 has a top speed of 368 mph and a range of 882 miles.

Specification

Basic

Year:
1950
Staff:
1

Production

[87 units]:
Fiat-Italy

Roles

- Fighter

- Education

Dimensions

Length:

9.47m

Width:

38.88 ft (11.85 m)

Height:

12.30 ft (3.75 m)

Weight

Curb Weight:

2,740 kg

MTOW:

3,400 kg

(difference: +1,455 pt)

Performance

1 x Rolls-Royce Merlin T. 24-2 inline piston engine producing 1,610 hp when the nose drives a three-bladed propeller.

Performance

Maximum Speed:

370 mph (595 km/h; 321 knots)

Service Limit:

41,010 ft (12,500 m; 7.77 mi)

Maximum range:

621 miles (1,000 km; 540 nautical miles)

Rate of climb:

715 m/min (2,345 ft/min)

Armor

Single-seat fighter/fighter trainer:

4 x 20mm Hispano wing guns

Two-seater coach (optional):

2 x 12.7mm Heavy Machine Guns (HMG)

Changes

G. 59 - Basic Series Names

G. 55AM - A modified Italian Air Force G. 55 aircraft powered by a Rolls-Royce Merlin engine; 12 examples.

G. 59-1A - Single-seat fighter/fighter-trainer aircraft of the Italian Air Force.

G. 59-1B - two-seater trainer of the Italian Air Force

G. 59-2A - Syrian Air Force single-seat fighter; 30 examples; 4 x 20mm wing guns (two per wing).

G. 59-2B - two-seat trainer for the Syrian Air Force; 10 examples; 2 x 12.7 HMG arms.

G. 59-3A - Navigation Trainer; only one prototype.

G. 59-4A - single-seat fighter of the Italian Air Force; 20 examples.

G. 59-4B - Two-seat trainer for Italian Air Force; 10 examples.
