History

The L96A1 is a sniper rifle manufactured by Accuracy International and is currently the sniper rifle of choice for the British Army. The L96 has an adjustable stock, an integrated adjustable bipod, and static iron sights (although the 6x42 Schmidt & Bender scope was standard on the original production model).

The L96 initially successfully competed with the Parker-Hale Model 85 rifle in the mid-1980s as the British Army's standard sniper rifle, replacing the aging Lee-Enfield L42A1 series. The construction process incorporates light alloys, plastics and metals into the design.

This fusion allows for greater field abuse (weapons may take a lot of external punishment but still keep the internal components in good working order).

The Accuracy International L96 Sniper Rifle is designed for 600 yards of first hits and 1,100 yards of harassing fire. It has been upgraded with new x3-x12 x50 scopes and sights. Some units are also equipped with the L115A1 Long Range Rifle (LRR), which fires an 8.59mm round, which is heavier than the L96's 7.62mm round and is less likely to be deflected at extreme distances. The free-floating barrel of the L96A1 is made of stainless steel and can be replaced within 5 minutes.

The system itself is designed to enable individual users to perform all but the most major repairs themselves in the field, the tools required are three Allen keys and a screwdriver.

The L96A1 is designed to fire the 7.62x51mm NATO cartridge from a 10-round detachable magazine. An adjustable bipod is mounted under the front barrel. The gun has a muzzle velocity of 2,790 feet per second.

The L96A1 can also be equipped with various scope mounts, collapsible stocks and silencers, and is commercially available. a soldier. Also available in 50 caliber (12.7 mm).

The L96 is part of Accuracy International's larger line of "Arctic Warfare" rifles for use in the military, special forces and law enforcement. The L96A1 is the British Army's designation for the Accuracy International PM ("Marksman") model, which entered the competition as the standard British sniper rifle.

International L96 Specification for Accuracy

Roles

- Manual Repeat Shot

- remote precision

Dimensions

Total length:

1,124 mm (44.25 in)

Run Length:

655 mm (25.79 in)

Weight (not loaded):

6.50 kg

Attractions:

Fixed; 6x42 Schmidt and Bender telescope.

Performance

Action:

Rotary Bolt Manual Bolt System

Muzzle velocity:

2,790 feet per second (850 meters per second)

Valid range:

3,608 ft (1,100 m; 1,203 yd)

Changes

PM "Precision Marksman" - International naming convention for accuracy in the British Army Rifle Competition.

AW "Arctic Warfare" - Improved PM model; special de-icing for cold weather; 7. 62x51mm NATO and 5. 56x45mm NATO forms.

AWF "Arctic Warfare Folding" - Side Folding Polymer Stock.

AWP "Arctic Warfare Police" - Improved "Arctic Warfare" model for law enforcement use.

AWS Arctic War Suppressed - Compatibility with Subsonic Ammunition.

AWC "Arctic Warfare Covert" - AWS model with folding stock; uses Delta Force and SAS.

AWM "Arctic Warfare Magnum" - Holds 7mm Remington Magnum and .300 Winchester Magnum cartridges.

AWSM "Arctic Warfare Super Magnum" - for the . 338 Lapua Magnum cartridge.

AW50 "Arctic Warfare .50 Caliber" - Based on AW; for .50 BMG (12.7x99mm NATO ammunition.

AW50F - Based on AW50; Australian designation; foldable shaft; toilet bowl.

AS50 "Arctic Semi-Automatic . 50 Calibre" - Used by the US Navy SEALs.

AE "Accuracy Enforcement" - Lower cost enforcement mode; 7. 62x51 NATO; 610mm barrel.

AICS "Accuracy International Undercarriage" 1. 0 - Fixed jaws.

AICS Accuracy International Chassis System 1. 5 - Adjustable cheeks.

AICS "Accuracy International Undercarriage" 2. 0 - hinge bearing; 210mm barrel length; adjustable chin.

L96A1 - British Army Designation of PM model

L115A1 - British Designation of AWSM; . 338 Lapua Magnum cartridge.

L115A3 - "Improved" L115A1 model.

L118A1 - British Army Designation of AWP model; 3-12x50 PM II Schmidt & Bender telescopic sights.

Psg 90 - Swedish Designation of AW model; Hensoldt (Zeiss) scope; sabot round capability.

G22 - Germany Army Designation of AWM; folding stock; . 300 Winchester Magnum cartridge (7. 62x67mm).

SR-98 - AW model for Australian military and police forces; folding stock.
