AEC Armored Car

History of AEC Armored Vehicles

The Associated Equipment Company (AEC) from London has been in the automotive field since 1912. With extensive experience in the manufacture of heavy trucks and similar vehicles, the company proved to be the perfect candidate for a private company supplying armored vehicles for multiple missions during World War II (1939-1945).

Based on the medium-range Matador 7.75 ton artillery tractor, the AEC armored vehicle was born as a light armored vehicle with considerable firepower for its time - indeed matching many tanks in circulation at the time. It was introduced to British military officials in 1941 and entered service within a short time, with production beginning in 1942.

From the looks of it, the AEC car appears to be a very useful product, without any bells and whistles. It features four large rubber tire wheels placed in the extreme corners of the chassis for good balance and stability. The design approach to the hull layout is multifaceted to provide basic ballistic protection against small arms fire and artillery jets - armor protection on various fairings ranges from 16mm to 65mm.

A typical crew consisted of three people, with the driver center in front of the turret (later designs would introduce a crew of four). The turret was taken from a Valentine infantry tank and used to store weapons. Standard armament starts with a QF 2-pounder supported by 1 x Besa machine gun.

The chassis is suspended in a 4x4 arrangement, with the power pack at the rear. Speeds up to 40 mph on roads up to 250 miles. The original car weighed 12 tons (short), and Marks further increased the weight to about 14 tons (short).

There are very few variants of AEC vehicles, starting with the original Mk I equipped with the Valentine's QF 2-Pdr tank turret. These are powered by AEC 195 series diesel engines, and around 129 examples have been completed to this specification. The Mk II was fitted with a new, stronger turret with a QF 6-pdr main gun and a revised hull front end, while being powered by an AEC 197 series diesel engine. The Mk III followed with a more powerful 75mm main gun - a variant designed to serve in a close support role. In fact, it was the brand that ended the AEC lineup.

A proposed self-propelled anti-aircraft vehicle (SPAA) appeared, armed with 2 Oerlikon automatic cannons, but the design was eventually abandoned when Allied air superiority was unchallenged.

Introduced in late 1942, the AEC armoured vehicle entered service immediately in key battles in North Africa, where its robust design and ease of operation proved to be a solid addition to the British Army's stockpile. In another service, the vehicle was subsequently used in the European theater of operations, by which time signs of future battlefield prowess had already emerged.

This AEC design was one of many Allied armored vehicles that saw extended military/security service in the postwar years, where it continued to perform its intended role for some time - as far-reaching as it was in 1976 (Lebanese Army).

A total of 629 AEC armored vehicles were completed in 1942-1943, joining other excellent WWII armored vehicle designs.

Specification

Basic

Roles

Dimensions

Performance

Performance

Armor

Varies by production brand.

Changes
